SYS-76HT
DSW-76 Section
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3:U.S.A. & Canada Model E2: Europe Model
Ref. No. nsp Part No. Part Name Remark Q'ty New
1 nsp 00D DSW 7600 001 Cabinet Ass'y BHKXDN055000 1 *
2 00D DSW 7600 002 Woofer LB7430400001 1 *
3 nsp 00D DSW 7600 003 Oak Feet JD5081000014 4
4 00D DSW 7600 004 Spikes JZ0071000002 4
5 nsp 00D DSW 7600 005 Screw LS1215010004 8
6 nsp 00D DSW 7600 006 Screw LS1215B07002 4
7 - Rear Sticker YS0480610019 1 *
11 nsp 00D DSW 7601 001 PREAMP P.W.B. UNIT 051-A00432A-E 1
12 nsp 00D DSW 7601 002 AMP P.W.B. UNIT 051-A00432B-E 1
13 nsp 00D DSW 7601 004 POWER P.W.B. UNIT for E3 051-A00434C-E 1
13 nsp 00D DSW 7601 003 POWER P.W.B. UNIT for E2 051-A00432C-E 1
14 - EVA 333-EVA-00783-0BAE 2
15 - WIRE CLAMP 163-11009-e 2
16 - EVA 333-EVA-00807-0BAE 2
17 - CASE 306-ABS-00206-1BBE 1
18 - BRACKET Large-R 361-FE-05008-0LBE 1
19 - HEAT SINK 309-ABS-05003-0BAE 1
! 20 00D DSW 7601 015 SUB TRANS for E3 150-e0351201-e 1
! 20 00D DSW 7601 014 SUB TRANS for E2 150-e0351200-e 1
21 - BRACKET Small-L 361-FE-05010-0LAE 1
22 - BRACKET Small-R 361-FE-05011-0LAE 1
23 nsp 00D DSW 7601 053 BACK PANEL for E3 302-AL-05021-2BBE 1
23 nsp 00D DSW 7601 052 BACK PANEL for E2 302-AL-05021-1BAE 1
! 24 00D DSW 7601 022 POWER SWITCH 180-prf1003s-e 1
! 25 00D DSW 7601 018 AC COARD for E3 152-u75201601-e 1
! 25 00D DSW 7601 019 AC COARD for E2 152-v75202601-e 1
26 - COVER 309-ABS-05003-0BAE 1
27 - HEAT SINK 323-AL-00019-0BBE 1
28 - BUSH 335-NYL-00002-0BAE 2
29 - RUBBER SHEET 25*21*2T 336-RUB-00263-0BAE 4
! 30 00D DSW 7601 017 MAIN TRANS for E3 150-e0865005-e 1
! 30 00D DSW 7601 016 MAIN TRANS for E2 150-e0865004-e 1
31 - M4 NUT 354-GM04002-J 4
32 - PWB HOLDER 61-FE-05013-0LAE 1
33 - EVA 333-EVA-00835-0BAE 2
34 - BRACKET Large-L 361-FE-05008-0LAE 1
35 - EVA 333-EVA-00826-0BAE 2
! 36 00D DSW 7601 020 FUSE 125V for E3 154-u25002t0-e 1
! 36 00D DSW 7601 021 FUSE 250V for E2 154-v12506t0-e 1
! 37 - CERAMIC C 4700P 130-3f472md00-e 1
38 - FUSE HOLDER R3-11 155-520020-e 1
39 - TUBE 20mm*40mm 156-h200040-e 1
40 - TUBE 20mm*60mm 156-h200060-e 1
41 - TUBE 7mm*120mm 156-h070120-e 1
43 - LED HOLDER7.5*7.1*8.25 361-NYL-05012-0BAE 1
45 - EVA 333-EVA-00220-0BAE 6
46 - EVA 333-EVA-05052-0BAE 4
