30
30SYS-T3L/SYS-C3L/SYS-A3L/SYS-A2.1L/SC-T3L/SC-A3L/DSW-3L
SYS-T3L PACKING VIEW
SYS-T3L PARTS LIST OF PACKING & ACCESSORIES
for Japan model
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Ref. No. Part No. Part Name Remarks Q'ty New
1 9H3 0001 310 SC-T3L 383750 4 *
2 9H3 0001 313 POLY BAG 387975 4 *
3 9H3 0001 312 POLY BAG 387970 4 *
4 9H3 0001 320 SC-C3L 383751 1 *
5 9H3 0001 158 POLY BAG 387969 1
6 9H3 0001 302 POLY FOAM 390573 1 *
7 9H3 0001 303 POLY FOAM 390574 1 *
8 9H3 0001 306 POLY BAG 383002 1
9 9H3 0001 308 CORD 388271 2 *
10 9H3 0001 307 CORD 388270 3 *
11 9H3 0001 309 PIN CORD 389804 1 *
12 9H3 0001 177 FOOT 381362 1
13 9H3 0001 301 OWNER'S MANUAL 391740 1 *
14 515 0918 209 SERVICE STATION LIST 363293 1
15 9H3 0001 304 GIFT BOX 388246 1 *
16 515 0919 004 GUARANTEE CARD(S) 390057 1
17 9H3 0001 305 BAR CODE LABEL 388733 1 *
18 9H3 0001 314 POLY BAG 375795 4 *
19 9H3 0001 321 SERIAL NO. LABEL 390094 1 *
for DSW-3L
Ref. No. Part No. Part Name Remarks Q'ty New
1 9H3 0001 340 DSW-3L 383749 1 *
2 9H3 0001 345 PROTECT SHEET 388209 1 *
3 9H3 0001 346 POLY BAG 367391 1 *
4 9H3 0001 352 POLY FOAM 387997 1 *
5 9H3 0001 317 POLY FOAM 387996 1 *
6 9H3 0001 316 GIFT BOX 388245 1 *
7 9H3 0001 343 POLY BAG 391885 1 *
8 9H3 0001 318 SERIAL NO. LABEL 390095 1 *
SYS-T3L Section
