31
31SYS-T3L/SYS-C3L/SYS-A3L/SYS-A2.1L/SC-T3L/SC-A3L/DSW-3L
SYS-C3L PACKING VIEW
SYS-C3L PARTS LIST OF PACKING & ACCESSORIES
for Japan model
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Ref. No. Part No. Part Name Remarks Q'ty New
1 9H3 0001 310 SC-T3L 383750 2 *
2 9H3 0001 313 POLY BAG 387975 2 *
3 9H3 0001 312 PLASTIC BAG 387970 2 *
4 9H3 0001 320 SC-C3L 383751 1 *
5 9H3 0001 158 POLY BAG 387969 3
6 9H3 0001 330 SC-A3L 388057 2 *
7 9H3 0001 333 POLY FOAM 390575 1 *
8 9H3 0001 332 POLY FOAM 390576 1 *
9 9H3 0001 314 POLY BAG 375795 2 *
10 9H3 0001 331 GIFT BOX 388244 1 *
11 9H3 0001 177 FOOT 389362 3
12 9H3 0001 308 CORD 388271 2 *
13 9H3 0001 307 CORD 388270 3 *
14 9H3 0001 309 PIN CORD 389804 1 *
15 9H3 0001 301 OWNER'S MANUAL 391740 1 *
16 515 0918 209 SERVICE STATION LIST 363293 1
17 9H3 0001 306 POLY BAG 383002 1
18 515 0919 004 GUARANTEE CARD(S) 390058 1
19 9H3 0001 335 BAR CODE LABEL 388734 1 *
20 9H3 0001 334 SERIAL NO. LABEL 390097 1 *
for DSW-3L
Ref. No. Part No. Part Name Remarks Q'ty New
1 9H3 0001 340 DSW-3L 383749 1 *
2 9H3 0001 345 PROTECT SHEET 388209 1 *
3 9H3 0001 346 POLY BAG 367391 1 *
4 9H3 0001 352 POLY FOAM 387997 1 *
5 9H3 0001 317 POLY FOAM 387996 1 *
6 9H3 0001 316 GIFT BOX 388245 1 *
7 9H3 0001 343 POLY BAG 391885 1 *
8 9H3 0001 318 SERIAL NO. LABEL 390095 1 *
