DENSO EUROPE B.V., 2003
Pressure Discharge Valve Common Rail HP3
: from Common rail
: to Fuel tank
Pressure discharge
valve
Common rail
Operation when fuel pressure
is higher than target injection
pressure
Operation when fuel pressure
is identical to target injection
pressure
