Specification Description
LED Indicators
Tri-colors (red, green, and blue): 1 LED to indicate communication, 4
LEDs for correct phasing (green when voltage and current on the same
phase; red when incorrectly wired, blue for wireless, Bluetooth wireless
technology, and Ethernet).
Communication
USB (Standard) USB standard (Type B). 1.8 M (6 FT) A-to-B USB Cable (included)
ETHERNET
(Standard)
Standard RJ-45 Connector supports 10/100 MB Ethernet over Cat 5 or
better. Configure for DHCP or Static IP address.
BLUETOOTH®
WIRELESS
TECHNOLOGY
(Optional)
Internal antenna: typical conditions <10ft up to 100ft range. Requires
Bluetooth wireless technology adapter on Window PC. Adapter must
support the Serial Port Profile (SPP).
WiFi ADAPTER
(Optional)
Internal WiFi adapter with two separate configurations:
Internal antenna: typical conditions <75ft up to 300ft
Power
Line Power Supply
From L1 Phase to L2 Phase. 80-600V (AC or DC) CAT III DC/50/60Hz, 125
mA, 5 W, or 10 VA max.
Non-user replaceable .5 Amp internal fuse protection.
Power In
(optional)
6-10 VDC maximum, 500 mA minimum
Mechanical
Operating
Temperature
-7 to + 60°C (20 to 140°F)
Humidity 5% to 95% non-condensing
Enclosure ABS plastic, 94-V0 flammability rating
Weight 340 g (12 ounces, excluding sensors and leads)
Dimensions 69 x 58 x 203 mm (2.7” x 2.2” x 8.0”)
