QUICK START GUIDE
The Quick Start Guide quickly gets you set up and operating with the new ELITEpro XC ™ and
ELOG 14 software and is recommended for those that have experience with DENT Instruments or
are familiar with power measuring products and procedures.
To set up the ELITEpro XC for any monitoring session the following items must be completed:
1) Current Transformers (CTs) must be connected to one or more of the channel inputs (unless
doing voltage-only measurements).
2) Line voltage connections must be made for any voltage or power measurements both for
measurement purposes and to power the ELITEpro XC.
3) A Setup Table that tells the meter how and what to measure must be created in the ELOG
software and loaded into the ELITEpro XC.
The information contained in the following section is provided as an example on how to set up a
single phase, 2-wire power measurement session using the ELITEpro XC and ELOG software. Use
this as a guide for your own monitoring project.
Install the ELOG 14 Software and the USB Driver
1) Install the ELOG Software onto your computer.
a) Insert the ELOG CD into your computer. The installation will run automatically. If it does
not, browse to the CD and locate the ELOG14Installer.exe program and double-click.
b) Perform the setup steps onscreen.
2) Install the ELITEpro XC driver on your computer.
a) Connect the USB cable to a USB port on your
computer, inserting the other end in the USB
port on the ELITEpro XC (Hint: Look for this USB symbol: ). If a USB cable is to be
used inside an electrical panel it must be rated to the appropriate voltage or wrapped in
an appropriately rated insulating sleeve. The DENT-supplied cable does not meet this
requirement without an insulating sleeve.
