Denver DCH-600 - Pre-Flight Adjustments and Flight Control; Binding and Throttle Calibration; Gyroscope Calibration and Trimming; Vertical Movement (Throttle)

ENG-7 ENG-8
1. Up / Down (Throttle)
Push the LEFT ST ICK left or right to
rotate the direction the drone is
facing (yaw).
Release the stick to stop rotating.
2. Rotate Direction
3. Move Left / Right
Push the RIGHT STICK left to move
left, or right to move right.
Release the stick to stop moving.
Push the RIGHT STICK forward to
move forward, or back to move
backwards.Release the stick to stop
moving.
4. Move Forward / Backwards
If the drone rotates when the stick
is centered, click this switch left
or right until the drone is stable.
5. Adjust Rotation Trim (Yaw)
FLIGHT CONTROL
Push the LEFT STICK forward to
make the drone go up, or backward
to go down (throttle). The throttle
will stay where you leave it.
NOTE: The drone will not operate unless you follow these steps in the order
listed.
1. First make sure the drone is OFF. Turn the controller / receiver ON. This
procedure must be followed precisely for the controller and drone to nd and
bind with each other.
2. The controller will beep once and the light will blink rapidly. Move the LEFT STICK
to the top and then to the bottom. The controller will stop blinking to show the
throttle is calibrated. Leave the stick at the bottom.
3. Now turn the drone ON by ipping the switch underneath the drone to the ON
position. After about 3 second the controller will beep “di do di”. The lights on
the drone will stop ashing. This shows the drone has become bound to the
controller.
4. Put the drone on level ground. Move the
RIGHT STICK on the controller in a circle.
The controller will beep “di do di” and
the drone lights will blink briey. This
calibrates the drone gyroscopes for level
ying.
Power Switch
PRE-FLIGHT ADJUSTMENTS
OFF ON
