5- 6 Protection device
Protection devices and emergency stop devices are provided for protection of the machine
against trouble during operation. When the running caution lamp lights, stop the engine
immediately. Check and remove the cause of trouble.
Table of protection device
action
warning
turn OFF the
circuit breaker
stop
the engine
indicate by
warning lamp function
high jacket
water
temperature
(WATER TEMP)
A
0 О
When the cooling water
temperature rises
abnormally, the device
acts.
Set point:101°C
oil pressure
failure
(OIL PRESS)
A
О О
When the oil pressure
falls abnormally, the
device acts.
Set point: 1. O x ЮОкРа
fuel level
failure
(FUEL LEVEL)
—
О
When fuel supply is
necessary because of
fuel shortage, the
device acts.
battery acid
level failure
(БАТТ LOW LEVEL)
—
О
When the battery acid
is failure, the device
acts.
oil filter
blinding
(OIL FILTER)
—
О
When replace of oil
filter Is necessary
because of blinding of
filter,the device acts.
air filter .
blinding
(AIR FILTER)
—
0
When replace or
cleaning of air filter
is necessary because of
blinding of filter, the
device acts.
overcurrent
О
— —
When overcurrent
floes,the device acts.
О : Device acts.
A : When the single—parallel change-over switch is parallel side, device acts.
