Derby cycle IMPULSE 2.0 SPEED - 12 Technical data

Original User Manual | Pedelec Impulse 2.0 speed 63
12 Technical data
MOTOR
Brushless electric motor with gear unit and eewheel
Output 350 W rated output
Gross weight
of electric drive,
battery, control unit
Freewheel motor
11 Ah 15 Ah 17 Ah
14.66 lbs 14.88 lbs 14.88 lbs
Control via torque sensor and rotational speed sensor in motor and speed sensor (on rear wheel)
BIKE TYPE
MAXIMUM PERMITTED GROSS WEIGHT
(bike, rider, luggage, trailer + load)
WEIGHT OF RIDER
Pedelec 286.60 lbs max. 231.49 lbs
IMPULSE LIION DOWN TUBE BATTERY
Voltage 36 V 36 V
Capacity 11 Ah 17 Ah
Energy con-
tent
396 Wh 612 Wh
Weight 6.39 lbs 6.39 lbs
Charging time 3 hours 4.5 hours
Cell 2.25 Ah 3.4 Ah
IMPULSE LIION SEAT TUBE BATTERY
Voltage 36 V 36 V 36 V
Capacity 11 Ah 15 Ah 17 Ah
Energy con-
tent
396 Wh 540 Wh 612 Wh
Weight 6.28 lbs 6.50 lbs 6.50 lbs
Charging time 4 hours 5 hours 6 hours
Cell 2.25 Ah 3.1 Ah 3.4 Ah
