Derby cycle IMPULSE 2.0 - | Version 2 | 04.2015 English

Original User Manual | Pedelec Impulse 2.0 35
Contents
1 Safety 38
1.1 General 38
1.2 Statutory requirements 38
1.2.1 Meaning for the rider 38
1.3 Battery 39
1.4 Charger 40
1.5 Motor 41
1.6 Adjustments/maintenance/repair 41
1.7 Transportation of the Pedelec 41
1.7.1 The Pedelec and your car 41
1.7.2 The Pedelec on trains 41
1.7.3 The Pedelec on aeroplanes 41
2 Composition of the vehicle 42
3 First steps 43
3.1 Checking the tightening torques 43
3.2 Fitting the pedals 43
3.3 Adjusting the saddle height 43
3.3.1 Clamping screw 43
3.3.2 Quick-release device 43
4 Quick start 44
5 Battery 45
5.1 Charging the battery 45
5.1.1 Removing the battery 46
5.1.2 Charging operation 46
5.1.3 Installing the battery 47
5.2 Battery information system 48
5.2.1 Checking the charge state 48
5.2.2 Checking the capacity 48
5.3 Battery management 49
5.3.1 Sleep mode 49
5.4 Warranty and service life 49
5.5 Storage 50
5.6 Shipping 50
5.7 Disposal 50
6 Charger 50
7 Control panel and display 51
7.1 Control panel 51
7.1.1 Switching on/o 51
7.1.2 Push assist 51
7.1.3 / buttons 51
7.2 Display small 52
7.2.1 Assistance indicator 52
7.2.2 Battery charge state indicator 52
7.2.3 Units 53
7.3 Display 53
7.3.1 Assistance indicator 53
7.3.2 Battery charge state indicator 53
7.3.3 Units 53
7.3.4 Remaining range indicator 53
7.4 Programming and settings 53
7.4.1 Drive data 54
7.4.2 Delete trip data 54
7.4.3 Delete overall data 54
7.4.4 Device settings 54
7.4.4.1 Display 54
7.4.4.2 Drive 55
7.4.4.3 Miscellaneous 56
7.4.5 Personalize 56
7.4.6 Target cost 56
8 The motor 58
8.1 Operation 58
8.2 Range 58
8.3 Riding your Pedelec eciently 59
8.4 Warranty and service life 59
9 Troubleshooting 60
10 Cleaning 61
10.1 Battery 61
10.2 Motor 61
10.3 Display 61
10.4 Control panel 61
10.5 Charger 61
11 Technical data 62
