www.desatech.com
108998-01E2
The BK and BKT blowers utilize the same rotary
squirrel cage type blower with magnetic attach-
ment and variable speed control. The BKT also
includes an additional thermostatically controlled
feature for use on some direct-vent models only.
The BK blower can be installed in wood burning,
B-vent and vent-free model replaces. Both the
BK and BKT blowers can be installed in direct-
vent model replaces. Blowers are installed by
accessing the blower compartment through the
lower louver panel or, on some models, through
the control access cover under the front refractory
panel (see Figure 1). The lower front louver panel
can be removed easily, see Removing Louver
Panel, page 3 for instructions.
Figure 1 - Accessing Blower Compartment (Controls Not
Shown for Clarity) B-Vent, Wood and Vent-Free Models
Front Refractory
Panel
Lower
Louver
Panel
Control
Access
Cover
Knockout
Plug
Figure 2 - Accessing Duplex Electrical Outlet Installed in
Bottom Right Side of Firebox
Duplex
Electrical
Outlet
WARNING: If there is a du-
plex electrical outlet installed in
the right side of the bottom of
-
ure 2), be sure that the electrical
power to the outlet is turned off
before proceeding with blower
may result in serious injury.
