INTRODUCTION
BEFORE BEGINNING THE INSTALLATION OF THE
FIREPLACE, READ THESE INSTRUCTIONS THROUGH,
COMPLETELY.
♦ This DESA fireplace and its components are safe
when installed according to this installation manual.
Unless you use DESA components, which has been
designed and tested for the fireplace system, you may
cause a fire hazard.
♦ The DESA warranty will be voided by and DESA
disclaims any responsibility for the following actions:
a) Modification of the fireplace, components, doors,
blower, fans, air inlet system and damper control.
b) Use of any component part not manufactured or
approved by DESA in combination with a DESA
fireplace system.
PROPER INSTALLATION is the most important step in
ensuring safe and continuous operation of the fireplace.
Consult the local building codes as to the particular
requirements concerned with the installation of all factory
built fireplaces. Although grounding may not be required by
code the manufacturer recommends it.
USE SOLID WOOD OR PROCESSED SOLID FUEL
FIRELOGS ONLY.
This fireplace is not intended to be used as a substitute for
a furnace to heat an entire home. Use for supplemental
heat only.
SELECTING LOCATION
To determine the safest and most efficient location for the
fireplace, you must take into consideration the following
guidelines:
1.) The location must allow for proper clearances (see
figures 1 & 2).
2.) Consider a location were the fireplace would not be
affected by drafts, air conditioning ducts, windows or
doors.
3.) A location that avoids the cutting of joists or roof
rafters will make installation easier.
4.) An outside air kit is available with this fireplace. For
more details refer to section on outside air kit
installation on page 3.
MINIMUM CLEARANCES TO COMBUSTIBLES
• Back and side of fireplace -------------- ¾” minimum
Note: The ¾” clearance is not required at the nailing flanges
• Floor* ------------------------------------- 0” minimum
*See step 2 of “Installing the Fireplace” on page 3
• Perpendicular Wall to Opening of unit - 12” minimum
• Top Spacers ------------------------------ 0” minimum
• Mantel Clearances ---------------------- see page 8
“Mantels”
• Chimney Outer Pipe Surfaces --------- 2” minimum
MINIMUM / MAXIMUM CHIMNEY HEIGHT
The minimum height of the chimney, measured from the base
of the fireplace to the flue gas outlet of the termination, is 14.5
feet for straight flue or a flue with one elbow set. The
maximum distance between elbows is 6 feet. For systems
with two elbow sets, the minimum height is 22 feet. The
maximum height of any system is 50 feet. This measurement
includes the fireplace, chimney sections and the height of the
termination assembly at the level of the flue gas outlet (see
page 7, figure 15).
FOR YOUR SAFETY
• Do not store or use gasoline or any other flammable
vapors or liquids in the vicinity of this or any othe
r
appliance.
• Due to high temperatures, the appliance should be
located out of traffic and away from furniture an
d
draperies.
• Do not place clothing or other flammable materials o
n
or near the appliance.
•
N
EVER leave children unattended when a fire is
burning in the fireplace.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause injury,
p
roperty damage, or loss of life. Refer to this manual fo
r
assistance or additional information. Consult a qualifie
d
installer or local distributor.
CHECK LOCAL CODES BEFORE
INSTALLING THIS FIREPLACE.
WARNING: Do not install a fireplace insert in this
b
ox unless the manufacturers instructions with the inser
t
specifically state this fireplace has been tested for use
with the insert.
This wood burning fireplace complies with UL 127-
CAN/ULS-S610-M87 standard as a FACTORY BUILT
FIREPLACE.
WARNING: Do not pack required air spaces wit
h
insulation or other materials.
FOR CANADA: The authority having jurisdiction (suc
h
as the municipal building department, fire department,
etc.) should be contacted before installation to determine
the need to obtain a permit.
WARNING: When processed wood fuel fire logs
are used, do not poke or stir the logs while they are
b
urning. Use only fire logs that have been evaluated fo
r
the application in fireplace and refer to fire log warnings
and caution markings on packaging prior to use.
