PARTS
MODELS TC106A, TC112A, TC113A, TC114A AND TC115A
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 9 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 113785-01 Cap 1
2 113781-01 Upper Shell 1
3 113825-01 Lower Shell 1
4 113778-01 Ring Shield 1
5 ** Base 1
6 116617-01 Ignitor Electrode 1
7 113777-02 Burner Ring Assembly 1
8 113790-01 Thermocouple 1
9 100898-01 Thin Hex Nut 2
10 102445-01 Piezo Ignitor Kit 1
11 098508-01 Valve Retainer Nut 1
12 121326-01 Control Knob 1
13 123632-01 Heat Shield 1
14 123631-01 Fuel Tube Assembly Kit 1
15 121992-01 Hose/Regulator Assembly, 10 foot 1
16 121513-01 Orice, LP 1
17 099460-01 Brass Hex Cap 1
18 116554-01 Automatic Valve 1
19 117059-01 Adapter, 1/4 FPT x 1/4 MPT 2
20 113795-01 Female Elbow Fitting, 1/4 FPT x 3/8 FLR 1
PARTS AVAILABLE - NOT SHOWN
117069-02 80,000 Btu/Hr Rating Decal 1
113808-07 Hang Tag (English) 1
113808-08 Hang Tag (Spanish) 1
113808-09 Hang Tag (French) 1
113805-04 Installation Decal (English) 1
113805-05 Installation Decal (Spanish) 1
113805-06 Installation Decal (French) 1
113802-29 Model Decal 1
116558-01 Control Position Decal 1
**Not a eld replaceable part
