PARTS
MODELS 200C, RCP200V(A), SPC-200C, TC107 AND TC200V(A)
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 9 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 113814-01 Pilot Assembly 1
2 113835-01 Hose/Regulator Assembly 1
3 113777-01 Burner Ring Assembly 1
4 113778-01 Ring Shield 1
5 113779-01 Fuel Tube Assembly 1
6 113780-01 Pilot Tube Assembly 1
7 114178-01 Upper Shell 1
8 113782-01 Orice Adapter 1
9 113783-01 Bracket, Pilot Mounting 1
10 113816-01 Orice, LP 1
11 ** Base 1
12 113785-01 Cap 1
13 100898-01 Thermocouple Clip Thin Hex Nut 2
14 113787-01 Control Valve 1
15 113788-01 Female Elbow Fitting, 1/4 FLR x 1/8 FPT 1
16 113817-01 Female Elbow Fitting, 1/4 FLR x 1/4 FPT 1
17 113790-01 Thermocouple 1
18 113821-01 Lower Shell 1
19 113812-01 Fitting, 1/4 FPT x 1/4 MPT 1
20 113793-01 Ball Valve 1
21 102445-01 Piezo Ignitor Kit 1
22 113794-01 Valve Nut, 1/2-28 1
23 113795-01 Female Elbow Fitting, 1/4 FPT x 3/8 FLR 3
24 113796-01 Retaining Ring 1
25 113797-01 Ignitor Electrode 1
26 113798-01 Heat Shield 1
27 115364-02 Pilot Orice 1
28 113801-01 Elbow Fitting, 1/8 FPT x 1/4 CPSN 1
PARTS AVAILABLE - NOT SHOWN
113809-01 Ball Valve Knob 1
113810-01 Ball Valve Knob Insert 1
117069-03 200,000 Btu/Hr Rating Decal 1
113808-01 Hang Tag (English) 1
113808-02 Hang Tag (Spanish) 1
113808-03 Hang Tag (French) 1
113805-01 Installation Decal (English) 1
113805-02 Installation Decal (Spanish) 1
113805-03 Installation Decal (French) 1
113802-19 Model Decal 1
**Not a eld replaceable part
