Desa VB42 Installation Instructions

- 11 - For more information, visit www.desatech.com
ILLUSTRATED PARTS
ITEM # PART # DESCRIPTION QTY. ITEM # PART # DESCRIPTION QTY.
1 106625-01 WARRANTY, HOME OWNERS BOOK 1 31 20046 TIEDOWN, GRATE 2
2 108307-01 PAN, INSULATION 1 *32 106574-01 INSTALL INSTRUCTION AK-6 1
3 108305-01 TOP, WRAPPER 1 *33 106586-01 LABEL, CERT. WARNOCK-HERSEY 1
4 108304-01 ASM, OUTER WRAPPER/INSULATION 1 *34 107778-24 LABEL, CARTON 1
5 108301-01 FLOOR, FIREBOX 1 *35 107132-02 CARTON, TOP 1
6 108303-01 SEPARATOR, AIR 1 *36 107133-02 CARTON, BOTTOM 1
7 106971-01 LINER, LEFT SIDE BRICK 1 *37 107143-01 LABEL, "CAUTION MOVING PARTS…" 1
8 106970-01 LINER, RIGHT SIDE BRICK 1 *38 107264-01 BRACKET, SHIPPING 1
9 108310-01 LINER, REAR BRICK 1 *39 107277-02 PLATE, RATING 1
10 108312-01 LINER, BOTTOM BRICK 1 *40 11105 SCREW 10 x 1/2 HWH LGM AB 96
11 108311-01 LINER, FRONT BOTTOM BRICK 1 *41 11164 SCREW #8 x 1/2 PH TR HD LGM 2
12 20060 PLATE, CIRCULATION 1 *42 11165 SCREW #18 x 5/8 MD TR BLACK OX 8
13 108300-01 TOP, FIREBOX 1 *43 11301 RIVET POP SD42BS STEEL 11
14 106967-01 WELDMENT, SIDE DAMPER 1 *44 11308 RIVET, ALUMINUM 4
**15 108298-02 WELDMENT, FRONT FACE 1 *45 11412 COTTER PIN 1-1/2 x 1/16 2
***15a 108298-01 WELDMENT, FRONT FACE 1 *46 14607 SWITCH, ROCKER 1
16 108302-01 DEFLECTOR, AIR 1 *47 14608 PLUG, MALE POLARIZED 1/4" 1
17 21198 PLATE, BLOWER ACCESS 1 *48 15214 LABEL, OUTSIDE AIR 1
18 109036-01 MANUAL, OWNERS 1 *49 15244 LABEL-WARNING DO NOT BLOCK 1
19 107001-02 GRATE, WOOD BURNING 1 *50 15246 LABEL-WARNING 3/4" AIRSPACE 2
20 108424-01 ASSEMBLY, SCREEN 1 *51 15303 LABEL-PRODUCT ID/ACCESSORIES 1
21 21366 RETAINER, INSULATION 1 *52 15310 LABEL-PRODUCT ID/CBKIII 1
22 20023 COLLAR, CHIMNEY STARTER 1 *53 16401 INSULATION RA-24 FOIL 4
23 20027 RETAINER, REFRACTORY 2 *54 16405 INSWOOL, BOX 1 x 3 X 33.5 1
24 20088 STOP, DOOR 1 *55 16408 INSULATION HT-23 1-1/2 x 44 1
25 20089 CLIP, PIVOT 2 *56 16901 STRAPPING 7/16 1 COIL = 900 20.75
26 20090 CLIP, SPRING 2 *57 17207 DUCT, FLEX 6" x 37-1/2 TYPE 1
27 106959-01 STANDOFF, TOP 4 *58 27251 LABEL ASSEMBLY, WARNING ALL 1
28 107128-01 CONDUIT, GAS 4 *59 27253 NOTICE: INDENTATION 1
29 108306-01 BOTTOM, WRAPPER 1 *60 27440 ELECTRICAL DUCT ASSEMBLY 1
30 108299-01 WRAPPER, FIREBOX 1 *61 54199 LABEL-REMOVE GAS KNOCKOUT 2
* ITEMS NOT SHOWN FOR CLARITY **FOR MODELS (V)B42L, (V)B42LI ***FOR MODELS (V)B42, (V)B42I

Desa VB42 Specifications

General

Brand	Desa
Model	VB42
Category	Indoor Fireplace
Language	English
