ILLUSTRATED PARTS BREAKDOWN
LOGSETS FOR MODELS
M36(B,H), M36P(B,H), VM36(B,H) AND VM36P(B,H)
KEY
NO.
PART
NUMBER
DESCRIPTION QTY.
- 107999-01 Log Set
1 108724-01 Right Front 9" Split Log 1
2 901098-01 Rear Log 1
3 108720-01 Top Right Log - 11
3
/
4
" 1
4 108721-01 Top Right Log - 16" 1
5 108722-01 Top Left Log - 13
1
/
2
" Y-Log 1
6 108723-01 Top Left Log - 11" 1
1
3
2
4
5
6
6
4
2B
3
5
2A
1
