Desa VM42P - Page 30

www.desatech.com
108795-01N30
KEY
NO.
PART
NUMBER DESCRIPTION QTY.
- 107999-02 Log Set
1 901098-02 Rear Log 1
2A 108723-01 Left Front Log - 11" 1
2B 108839-01 Right Front Log - 15
3
/
4
" Round 1
3 108722-01 Top Left Log - 13
1
/
2
" Y-Log 1
4 108838-01 Inside Top Left Log - 15
3
/
4
" Split 1
5 108721-01 Inside Top Right Log - 16" 1
6 108720-01 Top Right Log - 11
3
/
4
" 1
1
3
2
4
5
6
6
4
2B
3
5
2A
1
ILLUSTRATED PARTS BREAKDOWN
LOGSETS FOR MODELS
M42(B,H), M42P(B,H), VM42(B,H) AND VM42P(B,H)
