Pause July 2010
5 7
6
8
9
Position leg brackets in corners of bed frame. Fasten leg brackets to rails using M6
bolts and tighten with allen key provided. Attach legs to leg brackets using M6 bolts in
hole number 5.
Slide centre rail into metal fittings on headboard and tailboard tie rail.
Screw M8 metal dowels into threads in underside of headboard. Slide headboard on to
headboard tie rail.
Insert metal housings into holes at the back of the headboard tie rail. Attach nuts to
Attach tailboard tie rail in same manner as headboard tie rail. (steps 2-4)
Attach cover caps over fittings.
