DESKO PENTA Scanner - Technical Overview; Technical Data; Dimensions

Technical Specification Page 16 of 21
PENTA Scanner
®
Doc # 7 001 020 101 Doc.-Rev.: 2018-05-24
Technical Overview
Technical Data
Input Voltage:
5 V DC (max. tolerance ±5 %)
Max. tolerance voltage:
5 V DC ±5 %
Requirement for the
external Power supply unit:
according to IEC60950 – 1
or
PS2 classified IEC62368-1
Input Current:
2,5 A max
Storage Temperature:
-10 °C to +50 °C
Operating Temperature:
0 °C to +40 °C
Humidity:
20 % to 80 % (R.H. non-condensing)
Special conditions:
No direct sunlight on scan window
Reliability:
MTBF = 180.000 hours
RF / EMI Compliance:
Test report available upon request.
CE and FCC
Dimensions
PENTA Scanner
Footprint:
Detailed dimensional drawing is available upon request.
219. 9 mm (8.7 inches) x 150 mm (5.9 inches) x
144.7 mm (5.7 inches) // 191.2 mm (7.5 inches) with
touch display
Scan Window Size:
94 mm (3.7 inches) x 131 mm (5.2 inches)
Weight:
Approx. 1150 g (2.5 lb)
