Installation EN
30 / 84 03/2020
ELC-P-W
Press the trigger while inserting the battery pack. The reporting LED will blink.
Initial Configuration
Name, torque unit, speed unit, keypad beep, sleep mode
Go to the start screen and tap this icon.
Tap System > User interface > Display.
Customize the name of CONNECT.
Select the torque unit: Nm, ft lb, in lb, kg m, kg cm, oz in.
Select the speed unit: rpm or % of maximum tool speed.
Tick/untick "Keypad beep enabled" to enable/disable the beep sound.
Backlight auto off (sleep mode)
The screen will be automatically turned off after the timeout.
The screen will turn on as soon as the screen is touched or when a tightening result is displayed.
Back light timeout
The timeout value for the automatic switching off can be set between 1 and 60 minutes.
Tap this icon to validate.
How to change the language
Go to the start screen and tap this icon.
To Next Page
