Detection Systems Abacus User Guide
Chapter 4.27
At this display press 0/ESC key and then the 4 key to return to the Day mode, or carry out further tests
as follows.
Bell Test and Sounder Tests
At this display, press the 2 key for bell/sounder test.
At this display, press the 1 key to test the Bell (Siren) and Strobe.
At this display, the Bell (Siren) will sound and the Strobe will flash. Press
the 0/ESC key the bell (Siren) will stop but the strobe will continue to flash
until the panel is returned to the day mode.
At this display, press the 2, 3, or 4 key as required for the area sounder to
be tested. (Area sounders A2 and A3 are only available on the Abacus
8/80, 15R and 72 panels).
At this display, press the 1, 2, 3 and 4 key in turn to check different sounder
tones are working correctly at all sounders. When completed, press the
0/ESC key three times, followed by the 4 key, to return to the day mode.
Alarm Fault Display
Date Time Zone state or condition
If the descriptor message has been programmed, when reading the log press the
1 key for the additional information to be displayed for 2 second.
Zone No. Zone type or descriptor
See log information explained on next page.
Reading the Log
From the day mode, enter the Main or Master code.
(Version 5000 or later software, fast entry to log is available, if in day mode,
display reads Alarm, by pressing the YES/PART key twice).
At this display, press the NO key. (XXXXXX = Code holders name if
programmed).
On Version 7000 software, this display appears to allow you to return to the
day mode if you have made a mistake, press YES/PART key to continue.
At this display, press the NO key.
(If panel is in an alarm condition, this menu is not displayed).
1=Zone 2=Bell
