5 SECTION - TECHNICAL DATA
Table 2. Hydra Revolution – Technical specifications
Model Number POWER (KW@240V) POWER (KW@208V) Electric element #1 (kW) Electric element #2 (kW) Electric element #3 (kW) Electric element #4 (kW) Electric element #5 (kW) Electric element #6 (kW) Consumption (Amp @208V / @240V) VOLTAGE - FREQUENCY - PHASE Supply - Return Overall Dimensions (W x D x H) in Shipping Weight (Lbs)
HYDRAR15-E2401MA 15 11,3 5 5 5 NA NA NA 54 / 62
HYDRAR18-E2401MA 18 13,5 4 5 4 5 NA NA 65 / 75
HYDRAR20-E2401MA 20 15,0 5 5 5 5 NA NA 72 / 83
HYDRAR24-E2401MA 24 18,0 4 5 5 5 5 NA 86 / 100
HYDRAR27-E2401MA 27 20,3 4 4 5 4 5 5 97 / 112
HYDRAR29-E2401MA 29 21,8 4 5 5 5 5 5 104 / 120
In all cases, refer to applicable local and national codes
208/240V - 60Hz - 1
General information
6585
8,2 x 11,3 x 21,411,2 x 11,3 x 21,4
1" NPT Female
