Dettson HYDRAR15-E2401M - Parts List

18
Table 3. Parts list
ITEM Part Number 15 kw 18 kw 20 kw Description Comments
B04167-01 1 - - Boiler only (3 holes)
B04167-02 - 1 1 Boiler only (4 holes)
2 B04181 1 1 1 Triac support assembly Support and power card
3 B04172 - 1 1
4 B04171 1 - -
5 B04174 1 1 1 Cover assembly Cover, cosmetic and wiring diagram included
6 R02L007 1 1 1 Manometer LG 0-75PSI 1/4NPT
7 B04180 1 1 1 Thermodisc support assembly
8 G08F005 2 2 2 Reducer 1 x 3/4 Black
9 G11F025 1 1 1 Relief valve 30# 3/4m x 3/4f
10 B03970 3 4 4 Sealing gasket element
11 L99H015 3 2 4 Element (5 kw)
12 L99H014 - 2 - Element (4 kw)
13 F07F015 16 16 16 Hexagonal nut 5/16-18 brass
14 R02Z008 1 1 1 H2998 24LG temp sensor probe
15 G16G004 1 1 1 Female cap 1/4" NPT Black
16 G03F001 1 1 1 Coupling 1/4-18 NPT
17 G01G002 1 1 1 Nipple SD 1/4"NPT x 2" Black
18 B04178 1 1 1 End plate assembly Panel and warning label included
19 B03952 2 2 2 Wall bracket
20 B04201 2 2 2 Machine bracket
21 B04198 1 1 1 Jacket
22 B04193 1 1 1 Cabinet
23 B04202 1 1 1 Contour insulation
24 B04203 1 1 1 End insulation
25 G11Z002 1 1 1 Drain Faucet 3/4"m
26 L01J001 1 1 1 Breaker
27 B04194 1 1 1 Control support
28 L99F007 1 1 1 Terminal block
29 A20015 1 1 1 Outdoor sensor -12 C
30 B04204 1 1 1 Electrical panel Panel only
31 B04182-01 1 1 1 Triac protector assembly
32 A00421 1 1 1 Ext. sensor electrical wiring
33 F14G007 4 4 4 Card sleeve PC .315 CBDLS525
34 R99G020 1 1 1 Dettson control 2013 Control only
35 B04205 1 1 1 Electronic wiring
36 L01F010 1 1 1 Transformer 208/240/120
37 B04184 1 1 1 Aquastat support assembly Aquastat, bottom and support included
38 R99G006 3 4 4 Rectifier control
39 L01H030 3 4 5 Relay DPST 22VDC
40 A20009-07 3 4 4 Red wire element
41 A20009-06 3 4 4 Black wire element
1 Boiler assembly
Wiring panel assembly Panel with wirings included
