Change of Operation Mode - Standby Battery Charge / Standby Power Supply Mode:
If the DBL is now in state 'Standby Battery Charge Mode' the operation mode can be changed by pressing the MODE
push-button. The operation mode 'Standby Power Supply' is signalled via an asynchronous blinking of the three operation
LEDs (green/yellow, yellow).
LED 2/4 (green / yellow) and
LED 3 (yellow), alternate
- The DBL has been stopped and is now
in operation state 'Standby Power Supply'
Changeover from Standby to Power Supply Mode - Operation State / Functions:
If the DBL charger is in operation state 'Standby Power Supply', the operation in 'Power Supply Mode' can be started by
pressing the START/ STOP push-button. After the load detection circuit of the DBL has recognized the connection to a
resistive load, the DBL switches on and puts out constant voltage.
ATTENTION! Important Notes:
Batteries must not be connected while working in operation mode 'Power Supply'.
Any connected battery might put out gas, be destroyed or even explode due to over charge.
The 'Power Supply Mode' of the 28VDC DBL variants is only designed for 24VDC
on-board electrical systems - in this operation mode no vehicle with a different nominal on-board voltage may be
connected! The same also applies for the 'Power Supply' operation mode of the 14VDC DBL variants - it is only
designed for 12VDC on-board electrical systems. Please be aware that as a consequence of any non-
compliance a considerable damage could happen!
LED 2/3/4 (green / 2x yellow),
alternate blinking (ticker mode:
- The DBL charger is in operation mode 'Power Supply'
- ATTENTION! Batteries must not be connected while
working in operation mode 'Power Supply'
