SPECIFICATIONS
COOKTOP INSTALLATION
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50mm space shall be
preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by
the heat radiation from the hotplate. As shown below:
Model
CCT-B-4E-4Z-TOUCH-BK
Cooking Zones
4 Zones
Supply Voltage/Frequency
220-240V~, 50-60Hz
Rating Power
5490-6533W
Product Size L×W×H(mm)
590X520X52
Built-in Dimensions A×B (mm)
560X490
L（mm）
W（mm）
H（mm）
D（mm）
A（mm）
B（mm）
X（mm）
590
520
52
48
560
490
50 mini
