ELECTROVAP KIT MC
Installation - Step 3
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
KIT MC steam humidifier in 3 X 380V - 50/60 Hz
KIT MC
Production
(KG/St)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter transformer
5
5 5,7 6,4 4,2 Small 25 Loop
8
8 9,1 10 6,6 Small 25 Straight through
10
10 11,4 12,4 8,2 Small 25 Straight through
15-2
15 17,1 18,4 12,1 Small 25 Straight through
20
20 22,8 24,5 16,1 40 large 40 Straight through
30
30 34,3 36,5 24 40 large 40 Split
40
40 45,7 48,5 31,9 2 x 40 large 40 Straight through
50
50 57,1 60,5 39,8 2 x 40 large 40 Split
60
60 68,5 72,6 47,8 2 x 40 large 40 Split
KIT MC steam humidifier in 3 X 400V - 50/60 Hz
KIT MC
Production
(KG/St)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter transformer
5
5 5,5 6,2 4,24 Small 25 Loop
8
8 8,8 9,7 6,63 Small 25 Straight through
10
10 11 12 8,21 Small 25 Straight through
15-2
15 16,5 17,8 12,18 Small 25 Straight through
20
20 22 23,5 16,07 40 large 40 Straight through
30
30 33 35,1 24,01 40 large 40 Split
40
40 44 46,7 31,94 2 x 40 large 40 Straight through
50
50 55 58,3 39,88 2 x 40 large 40 Split
60
60 66 69,8 47,74 2 x 40 large 40 Split
