ELECTROVAP KIT MC
Installation - Step 3
ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL
KIT MC steam humidifier in 3 X 415V - 50/60 Hz
KIT MC
Production
(KG/St)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter transformer
5
5 5,3 6 4,26 Small 25 Loop
8
8 8,5 9,3 6,60 Small 25 Straight through
10
10 10,6 11,6 8,23 Small 25 Straight through
15-2
15 15,9 17,1 12,14 Small 25 Straight through
20
20 21,2 22,7 16,11 40 large 40 Straight through
30
30 31,8 33,9 24,06 40 large 40 Split
40
40 42,4 45 31,93 2 x 40 large 40 Straight through
50
50 53 56,2 39,88 2 x 40 large 40 Split
60
60 63,6 67,3 47,76 2 x 40 large 40 Split
KIT MC steam humidifier in 3 X 440V - 50/60 Hz
KIT MC
Production
(KG/St)
In Imaxi Pmaxi
Cylinder size
Steam Torroidal
( A ) ( A ) ( KW )
diameter transformer
5
5 5.3 5.7 4,29 Small 25 Loop
8
8 8.5 8.8 6,62 Small 25 Straight through
10
10 10.6 10.9 8,20 Small 25 Straight through
15-2
15 15,9 16.2 12,19 Small 25 Straight through
20
20 21,2 21.4 16,10 40 large 40 Straight through
30
30 31,8 32 24,08 40 large 40 Split
40
40 42,4 42.5 31,98 2 x 40 large 40 Straight through
50
50 53 53 39,88 2 x 40 large 40 Split
60
60 63,6 63.5 47,78 2 x 40 large 40 Split
