Specifications
Hose connections
Thread code
‘B’
‘N’
Air supply Atomising:
¼" BSP
¼" NPS
Diaphragm:
6mm push-in tube connector
6mm push-in tube connector
Coating material supply:
⅜" BSP
⅜" NPS
MAXIMUM RECOMMENDED WORKING PRESSURES
Atomising air supply
P1=7 bar (100 lbf/in2)
Diaphragm air supply
P3=7 bar (100 lbf/in2)
Coating material supply
P2=6 bar (87 lbf/in2
Air consumption:
SEE CHART 1
Weight
560g
