SB-E-2-609

E

E

P 1 - 8

OPERATION MANUAL

FLG3 —HVLP Gravity Spraygun

Table of Contents

Other manuals for DeVilbiss FLG3

Service Bulletin8 pages

Questions and Answers:

S
Shannon SmithJul 27, 2025
Why does my DeVilbiss Paint Sprayer produce runs and sags?
- J
  John WhiteJul 27, 2025
  Runs and sags in the paint finish when using a DeVilbiss Paint Sprayer can occur if there's too much material flow, the material is too thin, or the gun is tilted at an angle, or the gun motion is too slow. To fix this, adjust the gun or reduce the tip size, properly mix the material or apply light coats, and hold the gun at a right angle to the work surface while adapting proper gun technique.
M
Melissa SteeleAug 2, 2025
What to do if my DeVilbiss FLG3 leaves a thick, dimpled "orange peel" finish?
- J
  Jaime HamiltonAug 2, 2025
  A thick, dimpled finish, often referred to as "orange peel," when using a DeVilbiss Paint Sprayer can result from several factors: the gun being too close to the surface, too much material being coarsely atomized, air pressure being too low, using an improper thinner, the material not being properly mixed, or the surface being rough, oily, or dirty. Check the distance, normally 6-8 inches. Turn in the fluid adjusting screw or change to a smaller tip size. Increase air pressure or reduce fluid flow. Follow the paint manufacturer's mixing instructions and properly clean and prepare the surface.
R
Rachel MartinezAug 8, 2025
How to prevent a thin, sandy finish with my DeVilbiss FLG3 Paint Sprayer?
- P
  Paula HallAug 8, 2025
  A thin, sandy, coarse finish that dries before it flows out when using a DeVilbiss Paint Sprayer can be caused by the gun being too far from the surface, too much air pressure, or using an improper thinner. To resolve this, check the distance (normally 6-8 inches), reduce the air pressure and check the spray pattern, and follow the paint manufacturer's mixing instructions.
S
scotttravisAug 14, 2025
Why is fluid leaking from the front of my DeVilbiss FLG3?
- C
  celliottAug 14, 2025
  Fluid leaking or dripping from the front of your DeVilbiss Paint Sprayer can be due to several reasons: the packing nut being too tight, dry packing, a worn or damaged fluid tip or needle, foreign matter in the tip, a broken fluid needle spring, or using the wrong size needle or tip. Adjust and lubricate the parts. Replace the tip and needle, clean the tip, and replace the spring, needle, or tip as necessary.
A
Alicia BoothAug 20, 2025
How to fix fluid leaking from the packing nut on my DeVilbiss FLG3?
- W
  william72Aug 20, 2025
  Fluid leaking from the packing nut of a DeVilbiss Paint Sprayer is often due to a loose packing nut or a worn or dry packing. You can try to tighten the packing nut, being careful not to bind the needle. If that doesn't work, replace or lubricate the packing.

DeVilbiss FLG3 Specifications

General

Brand	DeVilbiss
Model	FLG3
Category	Paint Sprayer
Language	English

Summary

Operation Manual Introduction

Important Safety Advice

General safety advice before equipment use.

Product Description and ATEX Approval

Details ATEX approval, suitability, and technology.

EC Declaration of Conformity

Manufacturer's declaration of conformity to directives and standards.

Safety Warnings and Precautions

Fire, Explosion, and Material Hazards

Hazards of flammable materials, static electricity, and suitability for use.

Personal Protection and Training

Requirements for PPE, training, and material safety data.

Safe Operation and Misuse Prevention

Warnings on misuse, pressure limits, maintenance, and noise.

Parts List

Service Kit and Fluid Tip Sizes

Lists parts included in the service kit and fluid tip sizes.

Specifications and Materials

Technical Specifications

Lists air supply, pressure, temperature, and weight.

Materials of Construction

Details the materials used for gun body, nozzle, needle, and cup.

Installation Guide

Pre-use Preparation and Air Connection

Flush equipment with solvent and connect air supply.

Operation Procedures

Setup, Controls, and Spraying Technique

Adjusting controls, spray distance, overlap, and gun movement.

Preventative Maintenance

Cleaning, Lubrication, and Care

Procedures for cleaning gun, cup, air cap, and lubricating parts.

Parts Replacement

Component Replacement Procedures

Guidance on replacing nozzle, needle, packing, air valve, and spreader valve.

Accessories and Supplies

Tools, Lubricants, and Cleaning Products

Lists necessary tools, lubricants, and cleaning products.
