DeVilbiss FLG3 - Parts List; Service Kit and Fluid Tip Sizes

4
© 2003 ITW Finishing Systems and Products
Parts List
Ref. No Description Part Number Qty
1 Air Cap Retaining ring FLG-301 1
2
Aircap No3 FLG-1-3 1
3 Fluid Tip - 1
*4 Fluid Tip Seal (kit of 5) FLG-304-K5 1
5 Fluid Tip and Seal Kit See Below 1
6 Baffle FLG-305 1
7
Cup Gasket - 1
8 Spreader Valve - 1
* 9 Seal - 1
10 Bushing - 1
11 Seal, Bushing, Spring and Knob Kit - 1
12 Fluid Needle FLG-311 1
* 13 Needle Spring - 1
14 Needle Adjusting Knob - 1
*15 Air Valve - 1
*16 Air Valve Spring - 1
17 Air Valve Cap - 1
18 Air Valve Kit - 1
19 Air Inlet Adaptor - 1
*20 Trigger Screw - 1
21 Trigger - 1
*22 Trigger Stud - 1
23 Trigger, Stud and Screw Kit - 1
*24 Needle Packing - 1
25 Needle Packing Nut - 1
26 Needle Packing and Nut Kit - 1
27 Gravity C up Kit GFC-501 1
28 Cup Lid GFC-402 1
29 Drip Check Lid kit of 5 GFC-2-K5 1
30 Filter KGP-5 1
E
E
Fluid Tip and Seal Kit Size
FLG-302-15K 1.5mm
FLG-302-18K 1.8mm
Chart 1
* Parts included in service Kit FLG-488
