CONNECTORS (14, 15).
Remove connector (14 or 15) and clean threads in gun body. Apply a medium strength thread locking/sealing
compound to the taper thread of the new connector, screw into gun body and tighten. Recommended torque 16 Nm
(140 lbf in).
Accessories
Service kit Order KK-4998 contains parts marked with * in Parts List for figure 1.
Protective diaphragm Order AGN-8-K5. Converts gun for use with solvent based materials. Fit between the gun
body and standard rubber diaphragm.
Multipurpose spanner Order SPN-5. Contains necessary sizes for maintenance and hose connections.
Cleaning brush Order 4900-5-1-K3 for cleaning threads and recesses of gun.
Remote pressure Cup: maximum working pressure 2 bar (30 lbf/in2), capacity 2.0 litres.
Order hoses separately.
KB-522: NOT SUITABLE FOR USE WITH HYDROGENATED HYDROCARBON SOLVENTS OR WATERBOURNE
MATERIALS.
KB-522-SS: IS SUITABLE FOR USE WITH HYDROGENATED HYDROCARBON SOLVENTS OR
WATERBOURNE MATERIALS.
Pressure feed tanks: A range of sizes are available manufactured in zinc coated steel or stainless steel construction.
Please contact your local DEVILBISS Distributor for information.
