Devolo Home Control First Steps

25
Technical data
Produkt name Central Unit (MT:2600)
Protocols CSMA/CA (Powerline)
Z-Wave (Wireless))
Frequencies (Z-Wave) 868,40 MHz, 868,42 MHz, 869,85 MHz
Range Powerline: 300 m
Z-Wave: up to 25m inhouse, up to 100m outdoors
Security 128 Bit AES (Powerline and Z-Wave)
Buttons
1x dLAN (home icon) with LED (white/red)
1x Home Control (check mark) with LED (white/red)
Device port 1x Ethernet RJ45
1x USB 2.0 type A (for future extensions)
Usage indoor
Dimensions (without plug) 72 x 132 x 42 mm (BxHxT)
Operating temperature 0°C to +35°C
Ambient conditions 10 to 90% Humidity (non-condensing)
Power consumption Maximum: 4,6 W
Typical: 3,4 Watt
Certifications CE Class B (EU, CH, NO)
Other internal speakers (for future extensions)

Devolo Home Control Specifications

General

Type	Door/Window Contact
Technology	Z-Wave
Power Supply	Battery
Battery Life	Up to 2 years
Operating Temperature	0°C to 40°C
Range	Up to 30 m (indoors)
Compatibility	Z-Wave compatible gateways
