ENGLISH
10
3. Rotate the side handle to the desired position
and tighten the handle.
Setting the Drilling Depth (fig. 5)
1. Insert the required drill bit as described above.
2. Press the depth stop clamp (j) and keep it
depressed.
3. Fit the depth adjustment rod (h) through the
hole in the depth stop clamp.
4. Adjust the drilling depth as shown.
5. Release the depth stop clamp.
Forward/reverse Slider (fig. 6)
1. Push the forward/reverse slider (c) to the
LH-side for forward (RH) rotation. See arrows
on tool.
2. Push the forward/reverse slider (c) to the
RH-side for reverse (LH) rotation.
WARNING: Always wait until the motor
has come to a complete standstill
before changing the direction of rotation.
Fitting a Chuck Adapter and Chuck
(Sold Separately)
1. Screw a chuck onto the threaded end of the
chuck adapter.
2. Insert the connected chuck and adapter in the
tool as though it were a standard SDS Plus
®
bit.
3. To remove the chuck, proceed as for removing
a standard SDS Plus
®
bit.
WARNING: Never use standard chucks
in the hammerdrilling mode.
Consult your dealer for further information on the
appropriate accessories.
Replacing the Tool Holder with the
Chuck (fig. 1)
D25324
1. Turn the locking collar (k) into the unlocking
position and pull the tool holder/locking sleeve
(f) off.
2. Push the chuck (l) onto the spindle and turn the
locking collar into the locking position.
3. To replace the chuck with the tool holder, first
remove the chuck the same way as the tool
holder was removed. Then place the tool holder
the same way as the chuck was placed.
WARNING: Never use standard chucks
in the hammerdrilling mode.
Replacing the Dust Cover (fig. 3)
The dust cover (g) prevents dust ingress into the
mechanism. Replace a worn dust cover immediately.
1. Pull back the tool holder locking sleeve (f) and
pull the dust cover (g) off.
2. Fit the new dust cover.
3. Release the tool holder locking sleeve.
OPERATION
Instructions for Use
WARNING:
• Always observe the safety instructions
and applicable regulations.
• Be aware of the location of pipework
and wiring.
• Apply only a gentle pressure to
the tool (approx. 5 kg). Excessive
force does not speed up drilling but
decreases tool performance and may
shorten tool life.
• Do not drill or drive too deep to
prevent damage to the dust cover.
• Always hold the tool firmly with both
hands and ensure a secure stance
(fig. 7). Always operate the tool with
the side handle properly mounted.
Proper Hand Position (fi g. 1, 7)
WARNING: To reduce the risk of
serious personal injury, ALWAYS use
proper hand position as shown.
WARNING: To reduce the risk of
serious personal injury, ALWAYS hold
securely in anticipation of a sudden
reaction.
Proper hand position requires one hand on the side
handle (i), with the other hand on the main handle
(m).
Overload Clutch
If the drill bit becomes jammed or caught, the drive
to the drill spindle is interrupted by the overload
clutch. Because of the forces that occur as a result,
always hold the machine securely with both hands
and take a firm stance.
Switching On and Off (fig. 1)
1. To run the tool, press the variable speed switch
(a). The pressure exerted on the variable speed
switch determines the tool speed.
