DeWalt D25333 Instruction Manual

ENGLISH
25
D25334
B3
Voltage 120 V
Frequency 50-60 Hz
Power 950 W
No Load Speed 0–1150/min (rpm)
Impacts per Minute 0–5200 ipm
Impact Energy 3.5 J
Drilling Range 1/2" (13 mm) - 1-1/8" (28 mm)
Drill Capacity Max. 1-3/16" (30 mm)
Concrete 1-1/8" (28 mm)
Steel 1/2" (13 mm)
Wood 1-3/16" (30 mm)
Vibration Measurement 6.9 m/s
2
Weight 3.9 kg (8.6 lbs)

DeWalt D25333 Specifications

General

Carrying case	Yes
Chuck type	SDS Plus
Product color	Black, Yellow
Impact rate	5200 bpm
Idle speed (max)	1150 RPM
Sound power level	104 dB
Impact energy (max)	3.5 J
Sound pressure level	93 dB
Sound level uncertainty	3 dB
Vibration level (chiseling)	7.8 m/s²
Drilling diameter in steel (max)	13 mm
Vibration level (metal drilling)	2.5 m/s²
Vibration level (hammer drilling)	6.9 m/s²
Drilling diameter in concrete (max)	30 mm
Vibration level uncertainty (chiseling)	1.5 m/s²
Input power	950 W
Power source	AC

Weight and Dimensions

Depth	355 mm
Width	95 mm
Height	250 mm
Weight	3700 g
