Symbol Mode Application
Rotary Drilling Dry diamond coring
Rotary
Hammering
Drilling into concrete
andmasonry
Hammering
only
Lightchipping
To select an operating mode:
1. Depress the mode selector release button
5
.
2. Rotate the mode selector dial so that the arrow points to the
symbol corresponding for the desired mode.
NOTE: The arrow on the mode selector dial
4
must be pointing
at a mode symbol at all times. There are no operable positions
inbetween. It may be necessary to briefly run the motor after
having changed from 'hammering only' to 'rotary' modes in
order to align thegears.
Performing an Application (Fig.A, E)

WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
ofrotation.
1. Choose and install the appropriate chuck, adapter, and/or
bit onto to the tool. Refer to Bit and Bit Holder.
2. Using the mode selector dial
4
, selectthe mode
appropriate to desired application. Refer to
OperationModes.
3. Adjust the side handle
3
asnecessary.
4. Place the bit/chisel on the desired location.
5. Depress the trigger switch
1
.
6. To stop the hammer, release the switch.
Recommendations for Tool Operation
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drilling rate.
• Your hammer can be used for dry diamond drilling into
masonry up to 100 mm. For diamond drilling above this
diameter in masonry and regular large diameter diamond
drilling in masonry and concrete, we advise the use of
a dedicated diamond core drill. Follow the core bit or
manufacturer’s recommendations for using the accessory.
NOTE: Always use core bits with integral centredrill systems
and ensure the RPM (speed) of the hammer does not
exceed the maximum rated RPM of the diamond core.
- Insert the centredrill into its holder in the centre of the
core bit.
- Remove and unplug the machine.
- Remove the centredrill from its holder.
- Plug the machine in and insert the core bit into the
workpiece.

WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.
MAINTENANCE
Your DeWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Various types of SDS-Max bits and chisels are available as
anoption. Accessories and attachments used must be regularly
lubricated around the SDS-Maxfitment.
Consult your dealer for further information on the
appropriateaccessories.

DeWalt D25481 Specifications
