DeWalt D25614 Instruction Manual

1
ENGLISH
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about
this or any product, call
DeWALT
toll free at:
(1-800-433-9258).
1
Trigger switch
2
Side handle
3
Front barrel (collar)
4
Mode selector dial
5
Main handle
6
Bit holder
7
Sleeve
8
Lock-on button
9
Speed dial
10
E-Clutch® and brushwear
indicator LEDs
11
DeWALT
tool tag
mounting holes
Fig. A
4
3
7
6
1
8
5
11
9
10
2

DeWalt D25614 Specifications

General

Brand	DeWalt
Model	D25614
Category	Rotary Hammer
Language	English
