ENGLISH
3
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of workpatterns.
EC-Declaration of Conformity
Machinery Directive
Heavy-Duty Rotary Hammerdrill
D25733, D25773
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Director Engineering
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
02.11.2017
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
D25733 D25773
Voltage V
AC
230 230
(U.K. & Ireland only) V
AC
230/115 230/115
Type 1 1
No-load speed min
-1
177–355 145–290
No-load beats per minute bpm 1350–2705 1105–2210
Power input W 1600 1700
Single impact energy (EPTA 05/2009) J 13.3 19.4
Optimum drilling range into concrete
mm
25–38
28–42
Maximum drilling range in concrete
mm
48
52
Maximum core drilling range in
concrete
mm
40–125
40–150
Tool holdler SDS MAX SDS MAX
Weight kg 9.5 10.6
Noise values and vibration values (triax vector sum) according to EN60745-2-6:
L
PA
(emission sound pressure level) dB(A) 98 100
L
WA
(sound power level) dB(A) 109 111
K (uncertainty for the given sound
level)
dB(A) 3 3
Drilling
Vibration emission value a
h, HD
= m/s² 9.6* 12.4*
Uncertainty K = m/s² 1.5 1.5
Chiselling
Vibration emission value a
h
, Cheq
= m/s² 9.0* 11.7*
Uncertainty K = m/s² 1.5 1.5
* Measured at the side handle. Side handle vibration is higher than vibration at
the main handle.
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
English (original instructions)
HEAVY-DUTY ROTARY HAMMERDRILL
D25733, D25773
