Package Contents
The package contains:
1 Rotary hammerdrill
1 Side handle
1 Kit box
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Date Code Position (Fig. A)
The date code
13
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2017 XX XX
Year of Manufacture
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch
2
Side handle
3
Front Barrel (Collar)
4
Mode selector switch
5
Main handle
6
Bit holder
7
Locking sleeve
8
Lock-on switch
9
Electronic speed and
impact control dial
10
Red anti-rotation system
indicator LED
11
Yellow brushwear
indicator LED
12
DeWALT
tool tag mounting
holes
13
Date code
Intended Use
Your heavy-duty rotary hammer is designed for professional
masonry drilling and chiselingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your heavy-duty rotary hammer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Soft Start Feature
The soft start feature allows the tool to accelerate slowly, thus
preventing the drill bit from walking off the intended hole
position whenstarting.
The soft start feature also reduces the immediate torque
reaction transmitted to the gearing and the operator if the
hammer is started with the drill bit in an existinghole.
Active Vibration Control (AVC) System
For best vibration control, hold the tool as described in Proper
Hand Position and apply just enough pressure so the damping
device on the main handle is approximately midstroke.
The active vibration control neutralises rebound vibration from
the hammer mechanism. Lowering hand and arm vibration,
it allows more comfortable use for longer periods of time and
extends the life of theunit.
The hammer only needs enough pressure to engage the active
vibraton control. Applying too much pressure will not make
the tool drill or chip faster and active vibration control will
notengage.
DeWALT
Tool Tag Ready (Fig. A)
Optional Accessory
Your hammer comes with mounting holes
12
and fasteners
for installing a
DeWALT
Tool Tag. You will need a T20 bit tip to
install the tag. The
DeWALT
Tool Tag is designed for tracking and
locating professional power tools, equipment, and machines
using the
DeWALT
Tool Connect™ app. For proper installation of
the
DeWALT
Tool Tag refer to the
DeWALT
Tool Tagmanual.
Lock-On Switch (Fig. A)
Chipping mode only
The lock-on switch
8
offers increased comfort in extended use
applications. To lock the tool on, depress the lock-on switch
while the tool is running. The tool will continue to run after the
switch is released. To unlock and turn off the tool, depress and
release theswitch.
Electronic Speed and Impact Control (Fig. A)
The electronic speed and impact control allows the use of
smaller drill bits without the risk of bit breakage, hammerdrilling
into light and brittle materials without shattering and optimal
tool control for precisechiseling.
To set the electronic speed and impact control dial
9
, turn the
dial to the desired level. The higher the number, the greater
the speed and impact energy. Dial settings make the tool
extremely flexible and adaptable for many different appli cations.
The required setting depends on the bit size and hardness of
material beingdrilled.
