A. Trigger
B. Contact trip lock-off
C. Depth adjustment wheel
D. Headlights/low
battery/jam indicator
E. Jam clearing latch
F. Contact trip
G. Magazine
H. Pusher latch
I. Bump/sequential
selector switch
J. Reversible suspension
hook
K. Low nail indicator
Straight
Nail 5/8", 3/4", 1", 1-1/8", 1-3/16", 1-1/4", 1-5/16", 1-3/8", 1-1/2", 1-9/16", 1-3/4", 2"
Lengths (16 mm, 19 mm, 25 mm, 29 mm, 30 mm, 32 mm, 33 mm, 35 mm, 38 mm, 40 mm, 44 mm, 50 mm)
Shank Diameters 18 gauge
Nail Stick Angles 0˚
NAIL SPECIFICATIONS
TOOL SPECIFICATIONS
Defi nitions: Safety Guidelines
The definitions below describe the level of severity for
each signal word. Please read the manual and pay
attention to these symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
NOTICE: Indicates a practice not related to personal
injury which, if not avoided, may result in property
damage.
Firing Mode Selective
Voltage 18
Height 11.25" (286 mm)
Width 3.5" (89 mm)
Length 11.5" (292 mm)
Weight 7.5 lbs. (3.4 kg)
Magazine Angle 0˚
Loading Capacity Up to 110 nails
J
G
K
E
D
A
F
FIG. 1
H
B
C
I
