10
ENGLISH
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
The centre position of the control button locks the tool in the off
position. When changing the position of the control button, be
sure the trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
NOTE: The tool must come to a complete stop before changing
the tool's direction or running the tool in the oppositedirection.
Front Handle/Cable Lock (Fig.A)
The front handle
10
has a lock position and unlock position.
When pushed forward, the front handle will unlock allowing the
cable to be pulled out of or pushed into the drum. When pulled
backward, the front handle locks the cable intoposition.
Adjustable LED Worklight (Fig.A, C)
The adjustable LED worklight
7
(Fig. A) is located on the base
of the fixed drum shield
8
. The worklight switch
4
, Fig. C, is
located on the foot of the tool's main handle
3
. The worklight
is activated when the trigger switch is depressed. The low,
medium and spotlight modes can be changed by moving the
switch
4
. If the trigger switch remains depressed, the worklight
will remain on in allmodes.
When on low and medium settings, the beam will stay
illuminated for up to 20seconds after the trigger switch
isreleased.
Spotlight Mode
The high setting is the spotlight mode. The spotlight will run
for 20minutes after the trigger switch is released. Two minutes
before the spotlight will shut off, it will flash twice and then dim.
To avoid the spotlight shutting off, lightly tap the triggerswitch.

WARNING: While using the worklight in medium or
spotlight mode, do not stare at the light or place the
tool in a position which may cause anyone to stare
into the light. Serious eye injury couldresult.

CAUTION: When using the tool as a spotlight, be sure
it is secured on a stable surface where it will not cause a
tripping or fallinghazard.

CAUTION: Fully retract the cable into the drum before
using the tool as a spotlight. Personal injury or property
damage couldresult.
Low Battery Warning
When in spotlight mode and the battery is nearing complete
discharge, the spotlight will flash twice and then dim. After two
minutes, the battery will be completely discharged and the
tool will immediately shut down. At this point, replace with a
freshbattery.

WARNING: To reduce the risk of injury, always have a
back‑up battery or secondary lighting available if the
situation warrantsit.
Variable Speed Trigger Switch (Fig.A)
To turn the tool on, squeeze the trigger switch
2
. To turn the
tool off, release the trigger switch. The tool speed is controlled
by varying the triggerposition.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
Forward/Reverse Control Button (Fig.A)
A forward/reverse control button
1
determines the spin
direction of the cable and also serves as a lock‑offbutton.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
thetool.
To select reverse, release the trigger switch and depress the
forward/reverse control button on the left side of thetool.
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Forward/reverse control
button
2
Variable speed trigger switch
3
Main handle
4
Worklight switch
5
Battery pack
6
Battery release button
7
Adjustable LED Worklight
8
Fixed shroud
9
Drum cover
10
Front handle
11
Cable
12
Inner drum
13
Cable bulb end
14
Cable direction symbol
15
Date code
Intended Use
This drain cleaner is designed for professional drain
cleaningapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This drain cleaner is a professional power tool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.A)
The date code
15
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020 XX XX
Year of Manufacture
