WARNING: Always wear eye and other protective
equipment appropriate to thetask.

WARNING: Always wear leather work gloves with latex
glovesinside.

WARNING: Do not operate if more than 15cm of cable is
outside of pipe ordrum.

WARNING: The cable can whip ortangle.

WARNING: Do not hold cable while it isturning.

WARNING: Cable end feature may besharp.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
5. Remove the cable from the drum cover and front handle
and tuck it into the inner drum. Set the drum coveraside.
6. Carefully remove the inner drum with cable from
thedraincleaner.
7. When cleaning the cable, carefully uncoil the cable from the
inner drum. Refer to Cleaning underMaintenance.
To Install the Cable
1. Remove the battery pack from thetool.
2. Pull the front handle
10
out away from the tool to the
unlockedposition.
3. Remove the four screws from the drum cover
9
.
4. Fully wind the clean, dry cable into the inner drum
12
following the cable direction symbol
14
(Fig.A).

WARNING: Winding the cable in the wrong direction
could cause the tool to apply excessive torque causing the
cable to kink during bindup.

WARNING: Never install a new cable by threading it
through the front handle on the tool. Always disassemble
the drum cover so you can be sure the cable is wound in
the properdirection.
5. Place the inner drum with cable back into thetool.
6. Carefully pull the cable bulb end out of the inner drum and
feed it through the front handle.

WARNING: The cable is under stress and can unwind
unexpectedly. Keep pressure on the cable so it does
notunwind.
7. Place the drum cover and front handle over the inner drum
and reinstall the four screws. Tightensecurely.
NOTE: If the unit is unbalanced and/or vibrates
unnecessarily, the cable may be woundpoorly.
Cable Removal from the Drain Cleaner and
Cable Drum Installation (Fig.A)

WARNING: To reduce the risk of injury, wear safety
goggles or glasses with side shields. Always wear leather
gloves with latex gloves inside. The cable is under stress
and can uncoil unexpectedly. Cable end feature may
besharp.
Remove the cable for cleaning after eachuse.
To Remove the Cable
1. Remove the battery pack from thetool.
2. Pull the front handle
10
out away from the tool to the
unlockedposition.
3. With the tool supported vertically, remove the four screws
from the drum cover
9
.

WARNING: The cable is under stress and can uncoil
unexpectedly. Keep pressure on the drum cover so it does
notuncoil.
4. Carefully lift the drum cover up, reach underneath to hold
the cable firmly while pulling off the drum cover
9
and
front handle
10
to expose the inner drum
12
.
Inserting and Removing the Battery Pack
from the Tool (Fig.B)
NOTE: Make sure your battery pack
5
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
5
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
6
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
 
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only
DeWALT
battery packs andchargers.
