DeWalt DCD710 Instruction Manual

13
English
MAINTENANCE
WARNING: To reduce the risk of serious personal injury,
place the forward/reverse button in the lock-off position
or turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
Cleaning
WARNING: Blow dirt and dust out of all air vents with clean, dry air
at least once a week. To minimize the risk of eye injury, always wear
ANSI Z87.1 approved eye protection when performing this.
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool. These chemicals may
weaken the plastic materials used in these parts. Use a cloth
dampened only with water and mild soap. Never let any liquid get
inside the tool; never immerse any part of the tool into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect the charger from the AC
outlet before cleaning. Dirt and grease may be removed from the
exterior of the charger using a cloth or soft non-metallic brush. Do not
use water or any cleaning solutions.
Accessories
WARNING: Since accessories, other than those offered by DEWALT,
have not been tested with this product, use of such accessories with
this tool could be hazardous. To reduce the risk of injury, only D
EWALT
recommended accessories should be used with this product.
Recommended accessories for use with your tool are available at
extra cost from your local dealer or authorized service center. If you
need assistance in locating any accessory, please contact D
EWALT
Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286, call
1-800-4-D
EWALT (1-800-433-9258) or visit our website: www.dewalt.
com.
4. IF DRILL STALLS, it is usually because it is being overloaded
or improperly used. RELEASE TRIGGER IMMEDIATELY,
remove drill bit from work, and determine cause of stalling. DO
NOT CLICK TRIGGER ON AND OFF IN AN ATTEMPT TO
START A STALLED DRILL — THIS CAN DAMAGE THE
DRILL.
5. To minimize stalling or breaking through the material, reduce
pressure on drill and ease the bit through the last fractional part
of the hole.
6. Keep the motor running when pulling the bit back out of a
drilled hole. This will help prevent jamming.
7. With variable speed drills there is no need to center punch
the point to be drilled. Use a slow speed to start the hole and
accelerate by squeezing the trigger harder when the hole is
deep enough to drill without the bit skipping out.
Operation as a Screwdriver (Fig. 2)
Select the desired speed/torque range using the dual range gear
shifter (E) on the top of tool to match the speed and torque to the
planned operation.
Insert the desired fastener accessory into the chuck (F) as you
would any drill bit. Make a few practice runs in scrap or unseen
areas to determine the proper position of the clutch collar(D).
MAXIMUM RECOMMENDED CAPACITIES
Low Range (1) High Range (2)
BITS, METAL DRILLING 1/4" (6.35 mm) 1/8" (3.18 mm)
WOOD, FLAT BORING 3/4" (19.05 mm) 1/2" (12.7 mm)
HOLE SAWS 3/4" (19.05 mm) 5/8" (15.88 mm)

DeWalt DCD710 Specifications

General

Number of gears	2
Torque settings	15
Chuck capacity (max)	10 mm
Chuck capacity (min)	1 mm
Idle speed (1st gear)	400 RPM
Idle speed (2nd gear)	1500 RPM
Drilling diameter in wood (max)	20 mm
Maximum torque (hard applications)	24 N⋅m
Maximum torque (soft applications)	15 N⋅m
Vibration emission	2.5 m/s²
Product color	Black, Yellow
Chuck type	Keyless
Built-in light	Yes
Product design	Pistol grip drill
Number of batteries included	2 pc(s)
Power source	Battery
Battery voltage	10.8 V
Battery capacity	2 Ah

Weight and Dimensions

Depth	185 mm
Width	50 mm
Height	195 mm
Weight	1100 g
