DeWalt DCD710 Instruction Manual

DEWALT Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286
(NOV13) Part No. N376662 DCD710 Copyright © 2010, 2011, 2013 D
EWALT
The following are trademarks for one or more D
EWALT power tools: the yellow and black color scheme; the “D” shaped air intake grill; the array
of pyramids on the handgrip; the kit box configuration; and the array of lozenge-shaped humps on the surface of the tool.
DEWALT Battery and Charger Systems
Chargers/Charge Time (Minutes) – Chargeurs/Durée de charge (Minutes) – Cargadores de baterías/Tiempo de carga (Minutos)
Battery
Cat #
Output
Voltage
120 Volts 12 Volts
DC011 DC022 DC9000 DC9310 DC9320 DCB095 DCB100 DCB101 DCB102 DCB103 DCB106 DCB107 DCB112 DW911 DW9106 DW9107 DW9108 DW9116 DW9117 DW9118 DW9216 DW9226 DW0246 DCB119 DW0249 DW9109 DC9319
DC9360
36XX45XXXXXXX X X XXXXXXXXX X XXXXX
DCB361
36XX45XXXXXXX X X XXXXXXXXX X XXXXX
DC9280
28XX60XXXXXXX X X XXXXXXXXX X XXXXX
DW0242
24XXXXXX XXXX X X XXXXXXXXX X60X60XX
DCB200
20 X X X X X X X 60 60 60 140 140 90 X X X X X X X X X X 90 X X X
DCB201
20 X X X X X X X 30 30 30 70 70 45 X X X X X X X X X X 45 X X X
DCB203
20 X X X X X X X 35 35 35 90 90 60 X X X X X X X X X X 60 X X X
DCB204
20 X X X X X X X 70 70 70 185 185 120 X X X X X X X X X X 120 X X X
DCB207
20 X X X X X X X 30 30 30 60 60 40 X X X X X X X X X X X X X X
DC9096
18 60 60 X 60 60 X X X X 60 X X X 60 X X 60 60 20 X 60 130 X X X 60 60
DC9099
18 45 45 X 45 45 X X X X 45 X X X 45 X X 45 45 15 X 45 95 X X X 45 45
DC9180
18XXX6060XXXX60XXXXXXXXXXXXXXXX60
DC9181
18XXX3030XXXX30XXXXXXXXXXXXXXXX30
DW9096
18 60 60 X 60 60 X X X X 60 X X X 60 X X 60 60 20 X 60 130 X X X 60 60
DW9098
18 30 30 X 30 30 X X X X 30 X X X 30 X X 30 30 12 X 30 60 X X X 30 30
DW9099
18 45 45 X 45 45 X X X X 45 X X X 45 X X 45 45 15 X 45 95 X X X 45 45
DC9091
14.4 60 60 X 60 60 X X X X 60 X X X 60 90 60 60 60 20 115 60 115 X X X 60 60
DC9094
14.4 45 45 X 45 45 X X X X 45 X X X 45 60 45 45 45 15 90 45 90 X X X 45 45
DW9091
14.4 45 45 X 45 45 X X X X 45 X X X 45 60 45 45 45 15 90 45 90 X X X 45 45
DW9094
14.4 30 30 X 30 30 X X X X 30 X X X 30 45 30 30 30 12 60 30 60 X X X 30 30
DCB120
12XXXXX X40303030X6045XX X X X XX X X X45X XX
DCB127
12 X X X X X X X 35 35 35 X 90 60 X X X X X X X X X X 60 X X X
DC9071
12 60 60 X 60 60 X X X X 60 X X X 60 90 60 60 60 20 115 60 115 X X X 60 60
DW9050
12XXXXXX XXXX X X XX40XX X XXX X XXXXX
DW9071
12 45 45 X 45 45 X X X X 45 X X X 45 60 45 45 45 15 90 45 90 X X X 45 45
DW9072
12 30 30 X 30 30 X X X X 30 X X X 30 45 30 30 30 12 60 30 60 X X X 30 30
DW9048
9.6XXXXXXXXXX X X XX40XXXXXX X XXXXX
DW9061
9.6 45 45 X 45 45 X X X X 45 X X X 45 60 45 45 45 15 90 45 90 X X X 45 45
DW9062
9.6 30 30 X 30 30 X X X X 30 X X X 30 45 30 30 30 12 60 30 60 X X X 30 30
DCB080
8XXXXX60XXXXX X XXXXXX XX X XXXXXX
DW9057
7.2 30 30 X 30 30 X X X X 30 X X X 30 45 30 30 30 12 60 30 60 X X X 30 30
“X” Indicates that the battery pack is not compatible with that specific charger.
“X” indique que le bloc-piles n’est pas compatible avec ce chargeur.
Una “X” indica que el paquete de baterías no es compatible con ese determinado cargador.
All charge times are approximate. Actual charge time may vary. Read the instruction manual for more specific information.
Les durées de charge sont approximatives; la durée de charge rélle peut varier. Lire le manuel d’utilisation pour obtenir des renseignements plus précis.
El tiempo de duración de carga es aproximado; la duración de carga real puede variar. Lea el manual de instrucciones para obtener información más precisa.
* Maximum initial battery voltage (measured without a workload) is 12 volts. Nominal voltage is 10.8.
* La tension initiale maximum du bloc-piles (mesurée à vide) est de 12 volts. La tension nominale est de 10,8.
* El máximo voltaje inicial de la batería (medido sin carga de trabajo) es 12 voltios. El voltaje nominal es de 10,8.

DeWalt DCD710 Specifications

General

Number of gears	2
Torque settings	15
Chuck capacity (max)	10 mm
Chuck capacity (min)	1 mm
Idle speed (1st gear)	400 RPM
Idle speed (2nd gear)	1500 RPM
Drilling diameter in wood (max)	20 mm
Maximum torque (hard applications)	24 N⋅m
Maximum torque (soft applications)	15 N⋅m
Vibration emission	2.5 m/s²
Product color	Black, Yellow
Chuck type	Keyless
Built-in light	Yes
Product design	Pistol grip drill
Number of batteries included	2 pc(s)
Power source	Battery
Battery voltage	10.8 V
Battery capacity	2 Ah

Weight and Dimensions

Depth	185 mm
Width	50 mm
Height	195 mm
Weight	1100 g
