ENGLISH
35
d. Gear shifter
e. Keyless chuck
f. Battery release button
g. Battery pack
h. Worklight
INTENDED USE
This drill/driver is designed for light fastening and
drilling applications.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
This drill/driver is a professional power tool.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities, or for lack
of experience and/or for want of knowledge or
skills unless they are supervised by a person
responsible for their safety. Children should
never be left alone to play with this product.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.
Your DEWALT charger is double insulated
in accordance with EN 60335; therefore
no earth wire is required.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DEWALT service organisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal in
the plug.
• Connect the blue lead to the neutral terminal.
WARNING: No connection is to be
made to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.
Using an Extension Cable
An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: Prior to assembly and
adjustment, always remove the battery
pack. Always switch off the tool before
inserting or removing the battery pack.
WARNING: Use only DEWALT battery
packs and chargers.
Inserting and Removing the
Battery Pack from the Tool (fi g. 3)
WARNING: To reduce the risk
of serious personal injury, place
the forward/reverse button in
the lock-off position or turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories.
NOTE: Make sure your battery pack (g) is fully
charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack with the rails inside the
handle.
2. Slide it firmly into place until you hear the lock
snap into place.
TO REMOVE THE BATTERY PACK FROM THE TOOL
1. Press the release button (f) and firmly pull the
battery pack out of the tool handle.
2. Insert battery pack into the charger as
described in the charger section of this manual.
OPERATION
Instructions for Use
WARNING: Always observe the safety
instructions and applicable regulations.
WARNING: To reduce the risk
of serious personal injury, place
the forward/reverse button in
the lock-off position or turn tool
off and disconnect battery pack

DeWalt DCD710 Specifications

General

Number of gears	2
Torque settings	15
Chuck capacity (max)	10 mm
Chuck capacity (min)	1 mm
Idle speed (1st gear)	400 RPM
Idle speed (2nd gear)	1500 RPM
Drilling diameter in wood (max)	20 mm
Maximum torque (hard applications)	24 N⋅m
Maximum torque (soft applications)	15 N⋅m
Vibration emission	2.5 m/s²
Product color	Black, Yellow
Chuck type	Keyless
Built-in light	Yes
Product design	Pistol grip drill
Number of batteries included	2 pc(s)
Power source	Battery
Battery voltage	10.8 V
Battery capacity	2 Ah

Weight and Dimensions

Depth	185 mm
Width	50 mm
Height	195 mm
Weight	1100 g
