Torque Adjustment Collar (Fig. A)
Your tool has an adjustable torque screwdriver mechanism for
driving and removing a wide array of fastener shapes and sizes
and in some models, a hammer mechanism for drilling into
masonry. Circling the collar
3
are numbers, a drill bit symbol,
and in some models, a hammer symbol. These numbers are
used to set the clutch to deliver a torque range. The higher the
number on the collar, the higher the torque and the larger the
fastener which can be driven. To select any of the numbers,
rotate until the desired number aligns with thearrow.
Dual Range Gearing (Fig. A)
The dual range feature of your drill/driver allows you to shift
gears for greaterversatility.
1. To select speed 1 (high torque setting), turn the tool off and
permit it to stop. Slide the gear shifter
4
forward (towards
thechuck).
2. To select speed 2 (low torque setting), turn the tool off and
permit it to stop. Slide the gear shifter back (away from
thechuck).
NOTE: Do not change gears when the tool is running. Always
allow the drill to come to a complete stop before changing
gears. If you are having trouble changing gears, make sure that
the dual range gear shifter is either completely pushed forward
or completely pushedback.
Worklight (Fig. A)
There is a worklight
5
located just above the trigger switch
1
.
The worklight is activated when the trigger switch is depressed.
When the trigger is released the worklight will stay illuminated
for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Keyless Single Sleeve Chuck (Fig. G–I)
WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changingacces sories.
WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.
Your tool features a keyless chuck
6
with one rotating sleeve for
one-handed operation of the chuck. To insert a drill bit or other
accessory, follow thesesteps.
1. Turn tool off and disconnect tool from powersource.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 19 mm into the chuck and
tighten securely by rotating the chuck sleeve clockwise with
one hand while holding the tool with the other. Your tool is
equipped with an automatic spindle lock mechanism. This
allows you to open and close the chuck with onehand.
Be sure to tighten chuck with one hand on the chuck sleeve and
one hand holding the tool for maximumtightness.
To release the accessory, repeat steps 1 and 2above.
Belt Hook and Bit Clip (Fig. A)
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments oraccessories.
WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool’s belt hook
from a workbelt.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing the belt hook or bit
clip, use only the screw
8
that is provided. Be sure to securely
tighten thescrew.
The belt hook
7
and bit clip
9
can be be attached to
either side of the tool using only the screw
8
provided, to
accommodate left- or right- handed users. If the hook or bit clip
is not desired at all, it can be removed from thetool.
To move belt hook or bit clip, remove the screw
8
that holds
it in place then reassemble on the opposite side. Be sure to
securely tighten thescrew.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. C)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the top of the
drill
13
as shown, with the other hand on the main handle
14
.
Drill Operation (Fig. D)
WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect tool from power source
before making any adjustments or removing/installing
attachments oraccessories.
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
