DeWalt DCD7771 User Manual

ENGLISH
3
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.

WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.

CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
General Power Tool Safety Warnings

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCD7771-B1/A9/TW/KR DCD7771-IN DCD7781-B1/A9/TW/KR DCD7781-IN
Voltage
V
DC
18(20 Max) 18 18(20 Max) 18
Battery type
Li-Ion Li-Ion Li-Ion Li-Ion
Power output
W 340 340 340 340
No-load speed
1st gear
2nd gear
min
-1
min
-1
0–500
0–1750
0–500
0–1750
0–500
0–1750
0–500
0–1750
Impact rate
1st gear
2nd gear
min
-1
min
-1
–
–
–
–
0–8500
0–29750
0–8500
0–29750
Max. Torque (hard/soft)
Nm 65/26 65/26 65/26 65/26
Chuck capacity
mm 1.5–13 1.5–13 1.5–13 1.5–13
Maximum drilling capacity
Wood
Metal
Masonry
mm
mm
mm
30
13
–
30
13
–
30
13
13
30
13
13
Weight (without battery pack)
kg 1.15 1.15 1.2 1.2
English (original instructions)
CORDLESS COMPACT 13 mm DRILL/DRIVER/HAMMERDRILL
DCD7771, DCD7781
Batteries Chargers / Charge Times (Minutes)
Cat# V
DC
Ah Weight(kg)
DCB104 DCB107 DCB112 DCB113 DCB115 DCB118 DCB132 DCB119
DCB181 18 (20 Max) 1.5 0.35 22 70 45 35 22 22 22 45
DCB182/DCB204 18 (20 Max) 4.0 0.61 60/40** 185 120 100 60 60/40** 60 120
DCB183/DCB203 18 (20 Max) 2.0 0.40 30 90 60 50 30 30 30 60
DCB184/DCB205 18 (20 Max) 5.0 0.62 75/50** 240 150 120 75 75/50** 75 150
DCB185 18 (20 Max) 1.3 0.35 22 60 40 30 22 22 22 X
DCB187 18 (20 Max) 3.0 0.54 45 140 90 70 45 45 45 90
DCB189 18 (20 Max) 4.0 0.54 60 185 120 100 60 60 60 120
*
Date code 201811475B or later
**
Date code 201536 or later
