DeWalt DCD796P2 User Manual

1
Figure 1
I
H
Figure 2
K
J
P
A
B
C
D
F
G
H
E
DCD796
M
N
O
L

DeWalt DCD796P2 Specifications

General

Voltage	18V
Battery Type	Li-Ion
Max Torque	70 Nm
Chuck Capacity	1.5-13 mm
Hammer Action	Yes
Power Output	460 W
Max Torque (Soft)	27 Nm
Max. Drilling Capacity (Wood)	40 mm
Max. Drilling Capacity (Metal)	13 mm
Max. Drilling Capacity (Masonry)	13 mm
Battery Capacity	5.0 Ah
Tool-Free Chuck	Yes
LED Light	Yes
No Load Speed	0-2000 RPM
Beats per Minute (BPM)	0-9350/34000 bpm
