Performing an Application (Fig. A)
WARNING: To reduce the risk of personal
injury, ALWAYS ensure workpiece is anchored or
clampedfirmly.
WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
ofrotation.
Prior to Performing Work
• Set the speed selector
8
. Refer to SpeedSelection.
• Install the appropriate bit or accessory into the chuck.
Refer to accessory installation instructions in thismanual.
WARNING:
• Do not use this tool to mix or pump easily
combustible or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir flammable liquids
labeledaccordingly.
Spotlight Mode
The high setting is the spotlight mode
17
. The spotlight will
run for 20minutes after the trigger switch is released. Two
minutes before the spotlight will shut off, it will flash twice
and then dim. To avoid the spotlight shutting off, lightly tap
the triggerswitch.
WARNING: While using the worklight in On or
spotlight mode, do not stare at the light or place
the drill in a position which may cause anyone to
stare into the light. Serious eye injury couldresult.
CAUTION: When using the tool as a spotlight, be sure
it is secured on a stable surface where it will not cause a
tripping or fallinghazard.
CAUTION: Remove all accessories from the chuck
before using the drill as a spotlight. Personal injury or
property damage couldresult.
Low Battery Warning
When in spotlight mode and the battery is nearing complete
discharge, the spotlight will flash twice and then dim. After
two minutes, the battery will be completely discharged and
the drill will immediately shut down. At this point, replace
with a freshbattery.
WARNING: To reduce the risk of injury, always have a
back‑up battery or secondary lighting available if the
situation warrantsit.
Pivoting LED Worklight (Fig. A, G)
The pivoting LED worklight
9
capsule is physically adjustable
via three detent positions. The pivoting LED worklight
9
and its switch
10
are located on the foot of the tool. The
worklight is activated when the trigger is depressed. The
Off
15
, On
16
and spotlight modes
17
can be changed
by moving the switch on the foot of the tool. If the trigger
switch remains depressed, the worklight will remain on in
allmodes.
When in the On setting, the beam will automatically turn off
20seconds after the trigger switch isreleased.
Variable Speed Trigger and Forward/
Reverse Control Button (Fig. A)
The tool is turned on and off by pulling and releasing the
variable speed trigger
3
. The farther the trigger is depressed,
the higher the speed of the tool. Your tool is equipped with
a brake. The chuck will stop as soon as the trigger switch is
fullyreleased.
A forward/reverse control button
4
determines the
rotational direction of the tool and also serves as a
lock-offbutton.
• To select forward rotation (clockwise), release the trigger
and depress the forward/reverse control button on the
right side of thetool.
• To select reverse (counterclockwise), depress the
forward/reverse control button on the left side of
thetool.
NOTE: The center position of the control button locks the
tool in the off position. When changing the position of the
control button, be sure the trigger isreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
NOTE: The first time the tool is run after changing the
direction of rotation, you may hear a click on start up. This is
normal and does not indicate aproblem.
Proper Hand Position (Fig. F)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main
handle
14
and the other hand holding the battery pack
1
.
Installing and Removing the Battery Pack
(Fig. E)
WARNING: Ensure the tool/appliance is in the off
position before inserting the batterypack.
NOTE: For best results, make sure your battery pack is
fullycharged.
To install the battery pack
1
into the tool handle, align the
battery pack with the rails inside the tool’s handle and slide it
into the handle until the battery pack is firmly seated in the
tool and ensure that it does notdisengage.
To remove the battery pack from the tool, press the release
button
2
and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of thismanual.
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
