GB
User Manual
Notes
Specications
Laser Tool
Light Source Laser diodes
Laser Wavelength 620 – 630 nm visible (RED) 510 – 530 nm visible (GREEN)
Laser Power ≤1.50 mW (each beam) CLASS 2 LASER PRODUCT
Working Range 20 m (±65’) RED 35 m (±115’) GREEN
50 m with detector 60 m with detector
Accuracy (plumb) ±3 mm per 9 m (±1/8” per 30’)
Accuracy (Level): ±3 mm per 9 m (± 1/8” per 30’)
Indicators
Battery Low 1 x LED Flashing on Battery meter
Unit Not Powered Off With Pendulum
Lock Switch
4 x LED Flashing on Battery meter
Flashing Laser Beams Tilt range exceeded/unit is not level
Power Source 4 AA (1.5V) size batteries (6V DC) or 10.8V Dewalt Battery Pack
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Humidity Maximum relative humidity 80% for temperatures up to 31°C (88°F)
decreasing linearly to 50% relative humidity at 40°C (104°F)
Environmental Water & Dust Resistant to IP65
