FIG. 2
A
E
C
G
D
B
F
H
I
INTENDED USE
This cordless compact blower is designed for professional blowing
applications.
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
This cordless compact blower is a professional appliance. DO NOT
let children come into contact with the tool. Supervision is required
when inexperienced operators use this appliance.
ASSEMBLY
WARNING: To reduce the risk of serious personal injury,
turn tool off and remove the battery pack before making any
adjustments or removing/installing attachments or accessories.
An accidental start-up can cause injury.
CAUTION: Ensure the battery is removed before
removing extension attachment (A) or end attachment end (B). A
attachment must be attached to the housing before use.
Attachments (Fig. 3-5)
BLOWER
To connect the extension attachment,
end attachment or inflator/deflator
attachment to the blower outlet:
1. Line up the pegs (J) on the inside of
the attachemnt with the notches (K)
of the housing opening as shown in
figure3.
2. Push the attachment onto the
blower housing and turn left to lock.
Pull on the attachment to ensure it is
securely in place.
3. To remove the attachment, turn
right to unlock and pull it off of the
blower housing.
DEFLATOR
To connect the inflator/deflator
attachment to the deflator intake (I):
1. Line up the detents on the
attachment with the notches on the
top, bottom and sides of the intake.
2. Press the adaptor onto the intake.
3. To remove the attachment from
the tube or intake, pull the adaptor
away from the tool.
FIG. 3
A
J
J
K
K
I
FIG. 4
FIG. 5
